The Tascam Sonicview 24XP is a game-changer in digital mixing. Tailored for professional audio engineers and enthusiasts, this 24-channel console combines advanced technology with an easy-to-use interface. Ideal for live sound, studio recording, and broadcasting, it offers top-notch audio quality and a wide range of features.
What makes it stand out is the revolutionary TASCAM VIEW interface and multiple connectivity options like built-in Dante, USB, and SD recording. Its 54-bit float-point FPGA mixing engine ensures high-fidelity audio, perfect for both studio and live environments. It's designed for those who need flexibility, high performance, and powerful processing.
The console's expandable I/O lets you customize it to fit your needs, whether you have a complex setup or need to adapt to different recording scenarios. With dual 7-inch touchscreens and programmable user keys, it provides a user-friendly and fully customizable experience.
Key features include a TASCAM VIEW interface with three view modes, dual 7-inch touchscreens, up to 44 input channels, 22 output buses, high-performance processing, 32-bit/96kHz AD/DA conversion, TASCAM Class-1 HDIA microphone preamps, a 32-track SDXC recorder, built-in Dante, a 32-in/32-out USB audio interface, optional expansion slots, TASCAM Sonicview Control software, assignable user keys, motorized faders, and more.
Specifications: 52 inputs, 32 buses, 4 built-in FX, 32 USB Audio channels, 2 built-in players, SDHC/SDXC support up to 512GB, 32-in/32-out USB audio interface at 48 or 96 kHz, 32-bit, dimensions of 690.8(W) x 228.1(H) x 554.4(D) mm, weight of 18kg, power consumption of 85W, AC IN of 100-240V 50/60Hz, and operating temperature of 0 - 40 ℃.
Package contents: TASCAM Sonicview 24XP with integrated IF MTR32 recorder card, power cord (Japan, USA/EUROPE/OCEANIA), owner's manual with warranty, and TASCAM ID registration guide.
Using the Tascam Sonicview 24XP is straightforward. First, connect it to your power source using the provided power cord. Make sure the voltage matches your local supply (it supports 100 - 240V 50/60Hz). Then, connect your audio sources to the input channels. You can use the built - in Dante, USB, or other connectivity options depending on your setup.
To start recording, you can use the 32 - track SDXC recorder for standalone operation or connect it to your computer via the 32 - in/32 - out USB audio interface. The TASCAM Sonicview Control software allows you to control and edit remotely.
When it comes to mixing, use the dual 7 - inch touchscreens and the 24 + 1 motorized faders for hands - on control. You can assign functions to the 18 user keys and use the 7 custom fader layers and 8 DCA groups to streamline your workflow.
For output, you have multiple options including 22 flexible output buses. The main L/R bus has a 31 - band graphic EQ to fine - tune your sound.
Here are some important notes. Keep the console in an environment with a temperature between 0 - 40 ℃. Don't overload the input channels beyond their capacity to avoid distortion. When using the SD card, make sure it's formatted correctly and compatible (SDHC, SDXC up to 512GB).
For maintenance, regularly clean the touchscreens and the exterior of the console with a soft, dry cloth. Check the power cord for any signs of damage. If you're not using the console for an extended period, store it in a dry place. If you want to expand the functionality, you can use the optional expansion slots for MADI, Dante, AES/EBU, and analog outputs.
