The LD Systems ANNY 8 BPH B4.7 USA version is an outstanding portable Bluetooth PA speaker. It offers top - notch sound quality, perfect for professional audio setups. Whether it's for mobile sound systems, live events, or presentations, this battery - powered speaker is a great choice. With Bluetooth connectivity, you can easily stream audio wirelessly. It features an integrated mixer, multiple system presets, and audio effects like reverb and delay, ensuring a seamless performance in any venue, be it indoors or outdoors. Its highly portable design, combined with a long - lasting battery, allows for hours of operation without a power source. The speaker has a broad frequency response, deep bass, and excellent dispersion, so your audience will enjoy clear and powerful audio. Advanced features such as priority/ducking mode, a USB - C charging port for mobile devices, and Bluetooth 5.0 set it apart from competitors. Ideal for DJs, public speakers, and musicians.
**Key Features**
- Battery - powered portable Bluetooth PA speaker with an in - built mixer
- 8 - inch woofer for better bass and wide frequency range
- Class D amplifier with 80 W RMS and 160 W peak output
- Bluetooth 5.0 for wireless audio streaming
- Six - channel mixer with EQ, effects, and system presets
- USB - C port to charge mobile devices
- Durable ABS plastic housing suitable for indoor and outdoor use
- Up to 11 hours of battery life when fully charged
- Designed for DJs, live events, and professional audio applications
**Technical Specifications**
- Product Type: Battery - powered PA speaker
- Type: Set (1x ANNY 8, 1x receiver, 1x bodypack, 1x headset)
- Frequency Range: 470 - 490 MHz
- Weight: 8.8 kg
- System Output (RMS): 80 W
- System Output (Peak): 160 W
- Max. SPL Average (Sine burst): 110 dB
- Max. SPL Peak (Sine burst): 117 dB
- Frequency Response (-10dB): 53 - 20000 Hz
- Crossover Frequency: 1800 Hz
- Dispersion (H x V): 120° x 60 °
- Total Height: 390 mm
- Woofer Dimensions: 8 ' (203 mm)
- Width: 249 mm
- Woofer Magnet: Ferrite
- Depth: 282 mm
- Woofer Voice Coil (inch): 1.5 '
- Woofer Voice Coil (mm): 38 mm
- Cabinet Construction: Bass Reflex
- Housing Material: ABS plastic
- Tweeter Dimensions: 1 ' (25 mm)
- Tweeter Magnet: Ferrite
- Tweeter Voice Coil: 1 '
- Tweeter Voice Coil (mm): 25 mm
- Amplifier Module: Class D
- Protection Circuits: Short circuit, thermal overload
- Ambient Temperature (Operating): 0°C - 40 °C
- Relative Humidity: 0 - 80% (non - condensing)
- Fuse: T2 AL 250V
- Mains Connector: IEC
- Operating Voltage: 100 V AC - 240 V AC, 50 - 60 Hz
- Power Consumption: 150 W
- Physical Inputs: 5
- Input Connectors: 2 x 6.3 mm / XLR combo, 2 x RCA, 3.5 mm jack
- Mix Output: 1
- Mix Output Connector: XLR male
- Bluetooth Standard: 5.0
- Bluetooth Audio Decoder: AAC, SBC
- Rechargeable Battery: 14.8V / 5Ah (Li - Ion rechargeable battery)
- Indicator Battery: 4 - segment LED
- Battery Life (MUSIC, Full Volume): 3.5 Hours
- Battery Life (ECO, Mid Volume): 11 Hours
- Charging Time (80%, No Signal): 3 hours
- Charging Time (Full Recharge): 5 hours
- LDANNYBPB47US - Bodypack Transmitter for ANNY®: Battery - powered PA speaker accessories
- Type: Bodypack
- Transmission Frequency Range: 470 - 490 MHz
- Frequency Response: 45 Hz - 20 kHz
- Channels: 12
- Inputs: Mini - XLR (3 - pin)
- Signal - to - noise Ratio: 100 dB
- Rated HF Output Power: 10 mW
- Power Supply: 2 x AA battery
- Operating Time: >8 h (with alkaline batteries)
- Dimensions (Width x Height x Depth): 64 mm x 100 mm x 21 mm
- Weight: 0.09 kg
- LDANNYRB47US - Receiver Module for ANNY®: Battery - powered PA speaker accessories
- Type: Receivers
- Modulation Type: FM
- Transmission Frequency Range: 470 - 490 MHz
- Frequency Response: 50 Hz - 17 kHz
- Channels: 12
- Weight: 0.08 kg
- LDWS100MH1 - Headset Microphone: Wireless Microphone System Accessories
- Type: Headsets
- Frequency Response: 100 Hz - 12 KHz
- Directivity: Cardioid
- Nominal Impedance: 680 Ohm(s)
- Phantom Power Requirements: 5 V
- Microphone Input: Mini - XLR (3 - pin, female)
- Cable Length: 1 m
- Accessories (Included): Foam windscreen
- Weight: 0.049 kg
Using the LD Systems ANNY 8 BPH B4.7 is a breeze. First, make sure the battery is charged. You can check the battery indicator on the speaker. If it's low, plug it in using the power adapter and wait for it to charge. It takes about 3 hours to reach 80% and 5 hours for a full recharge. When you want to play audio wirelessly, turn on the Bluetooth on your device and pair it with the speaker. The speaker supports Bluetooth 5.0, so the connection will be fast and stable. You can also connect other devices like microphones or music players using the various input connectors. For the headset microphone, just plug it into the appropriate input on the speaker. When it comes to using the mixer, there are multiple system presets that you can choose from to get the best sound for your event. You can also adjust the EQ and add effects like reverb and delay.
Here are some important notes. Don't operate the speaker in extremely hot or cold temperatures. The ideal operating temperature is between 0°C and 40°C. Also, keep the relative humidity between 0 - 80% and make sure it's non - condensing. When using the battery - powered mode, if you want longer battery life, switch to ECO mode and set the volume to mid - level. This can give you up to 11 hours of playtime.
For maintenance, clean the speaker regularly with a soft, dry cloth. Avoid using harsh chemicals or abrasive materials. Check the cables and connectors periodically to make sure they are in good condition. If you're not using the speaker for a long time, store it in a dry place and charge the battery every few months to keep it healthy.
