VigilLink CTRL AVoIP Controller, Optimized for JP4K3K and JP4K6K
The VigilLink VLIP - H51G - CTRL is a top - notch network control module tailored for professional AV setups. It's a must - have for modern AV systems, thanks to its strong network connectivity and dependable control features. With dual 100M LAN ports that support Power over Ethernet (POE), it easily fits into existing networks, slashing the need for extra power supplies and streamlining installation.
This module supports control via IR, digital I/O, and RS - 232, making it super versatile and compatible with a wide array of devices. It's built to last, housed in a metal enclosure that protects it and ensures a long lifespan in various settings. Its compact design lets it fit neatly into racks or cabinets, perfect for both small - scale and large - scale installations. Operating from 32°F to 104°F (0°C to 40°C), it suits most professional AV environments. And with a low power consumption of just 4.5W, it offers energy - efficient long - term operation without sacrificing performance.
The VLIP - H51G - CTRL boasts excellent transmission capabilities, reaching up to 100 meters with CAT 5E/6/6A/7 cables. Its diverse control ports like IR, digital I/O, and RS - 232 make it great for many applications such as video walls, control rooms, and live events. With an easy - to - use interface and flexible control options, it's the go - to choice for pros seeking a reliable and efficient network control solution.
Key Features:
- Dual 100M LAN ports with POE support for seamless network integration
- Multiple control options including IR, digital I/O, and RS - 232 for wide - ranging compatibility
- Compact and durable metal enclosure for protection and long - term use
- Low power consumption (4.5W) for energy - saving operation
- Transmission distance of up to 328 feet (100 meters) with CAT 5E/6/6A/7 cables
- Operating temperature range of 32°F to 104°F (0°C to 40°C) for versatile applications
Technical Specifications:
Network Bandwidth: 100M
Transmission Distance: 328 feet (100m) CAT 5E/6/6A/7
Control Ports:
- 2 x 100M LAN [RJ45 connector] [VIDEO LAN support POE]
- 1 x IR IN [3.5mm audio jack, 12V level]
- 1 x DIGITAL I/O [6 - pin 3.81mm Phoenix connector]
- 1 x RS - 232 [3 - pin 3.81mm Phoenix connector]
Dimensions: 8.03' [W] x 3.86' [D] x 0.83' [H]
Housing: Metal enclosure
Color: Black
Weight: 1.12 lbs
Power Supply: 12V/1A
Power Consumption: 4.5W
Operating Temperature: 32°F ~ 104°F / 0°C ~ 40°C
Storage Temperature: - 4°F ~ 140°F / - 20°C ~ 60°C
Relative Humidity: 20~90% RH (No condensation)
Using the VigilLink VLIP - H51G - CTRL is a breeze. First, connect it to your existing network using the dual 100M LAN ports with POE support. This way, you don't need to worry about extra power supplies. Then, connect your devices to the appropriate control ports like IR, digital I/O, or RS - 232. You can easily control a variety of devices in your AV setup, whether it's a video wall or a control room. When it comes to the environment, make sure the temperature is between 32°F and 104°F (0°C and 40°C). Avoid using it in areas with high humidity or where condensation might occur. For maintenance, keep the metal enclosure clean. If there's dust on it, you can use a soft, dry cloth to wipe it. Also, check the cables regularly to ensure they're properly connected. With proper use and maintenance, this controller will serve you well for a long time.
