Product Description
The Digital Forecast Bridge 1000 SDA is an outstanding HD/SDI 4 x 1 selector distribution amplifier. It can take an SDI signal, select it, and then output four SDI signals. This amplifier supports up to 1080p60 format, offering high - quality video output. You can easily control it remotely via RS - 232 or RS - 422 communication. Key features include: being a HD/SDI 4 x 1 selector DA, having 4 HD/SDI select inputs (SD/HD/3G), outputting 1 selected source to 4 HD - SDI outputs (SD/HD/3G), enabling RS422 or RS232 remote control, and having a wide DC 7V - 24V operating range. In terms of technical specs, it has dimensions of 106 x 96 x 30 (mm), weighs 225 g, operates at +12 VDC, consumes a maximum of 5 Watts (4.27 Watts on average), can work in humidity from 0 to 95% RH without condensation, and supports multiple SDI formats like NTSC, PAL, 720p, 1080i, 1080p, and 1080p 3G.
Using the Digital Forecast Bridge 1000 SDA is quite simple. First, connect your SDI sources to the 4 HD/SDI select inputs. Then, select the source you want to use. The amplifier will automatically output this selected source as four SDI signals. You can control it remotely using an RS - 232 or RS - 422 connection. When it comes to power, make sure to use a DC power supply within the 7V - 24V range. Keep the device in a place with humidity between 0 and 95% RH to avoid condensation. For maintenance, keep it clean and free from dust. If there are any issues, check the power connection and the communication settings first.
