The new generation of the Crown XLS1002 DriveCore power amplifier is here with a fresh, sleek look. It features a three - times larger LCD display and more advanced DSP capabilities. Using Crown's patented DriveCore technology, it's ultra - efficient. With a 4Ω bridged connection, it can deliver 2400W with plenty of headroom, ensuring a clean and undistorted sound to your speakers. Whether it's a small club or a large concert venue, this amplifier provides a powerful and pure sound experience.
Key Features:
- Ultra - light Class D amp (less than 11 lb or 5 kg) with Crown's DriveCore tech.
- Enhanced DSP for more control, including a band - pass filter per channel.
- Smart lighting control: Turn off most LEDs in dark venues.
- Selectable input sensitivity (1.4Vrms and .775Vrms) for full - power operation.
- Auto sleep mode for energy savings.
- Security setting to lock the menu.
- System reset to restore factory settings.
- Remote power trigger for convenience.
- Peakx Limiters to protect speakers and maximize output.
- Multiple input options (XLR, 1/4', RCA) for flexibility.
- Integrated PureBand Crossover System for better performance.
- Efficient fans to prevent overheating.
Technical Specifications:
- Sensitivity: 1.4Vrms
- Frequency Response: +0dB, -1dB
- Signal to Noise: > 97dB (at .775Vrms sensitivity, 6dB lower)
- Intermodulation Distortion: < 0.3%
- Damping Factor: > 200
- THD: < 0.5%
- Crosstalk: At 1kHz: > 85dB, At 20kHz: > 55dB
- Dimensions: 19' (48.3 cm) x 3.5' (8.9 cm) x 7.7' (19.6 cm)
- Weight: 8.6 lbs (3.9 kgs)
Using the Crown XLS1002 DriveCore power amplifier is easy. First, connect your audio source to one of the available inputs - XLR, 1/4', or RCA. You can select the input sensitivity based on your needs, either 1.4Vrms or .775Vrms. Then, connect your speakers to the amplifier's output. You can adjust the settings on the amplifier using the LCD display and the menu buttons.
When using the amplifier, make sure it has enough ventilation. The efficient forced - air fans are there to prevent overheating, but a well - ventilated area will help it work better. Also, avoid exposing it to extreme temperatures or humidity.
For maintenance, keep the amplifier clean. You can use a soft, dry cloth to wipe it down. If there's dust inside, use compressed air to blow it out gently. You can set the security setting to lock the menu if you don't want anyone to accidentally change the settings. And if you ever need to restore the factory settings, just use the system reset function.
